BMW Alloy Wheel Bolts Fitment Guide

[vc_row][vc_column width=”1/2″][vc_column_text]Do you need to know BMW alloy wheel bolts fitment for your car?

Bolts are used by BMW and around 2010 when BMW started introducing the F models, eg 3 series F30, they also changed the thread size of the bolts. Below is a break down of each spec and the cars that fit them.

This guide is for BMW alloy wheel bolts standard fitments. If you have spacers fitted or aftermarket wheels you might need extended bolts or wheel studs. If you are not sure please contact us for assistance.[/vc_column_text][/vc_column][vc_column width=”1/2″][vc_single_image image=”8106″ img_size=”large” alignment=”center” css_animation=”appear” title=”BMW”][/vc_column][/vc_row][vc_row][vc_column][vc_column_text]

Standard fitment BMW alloy wheel bolts



[/vc_column_text][/vc_column][/vc_row][vc_row][vc_column width=”1/4″][vc_empty_space height=”30″][vc_row_inner][vc_column_inner width=”1/2″][vc_column_text]Model
Year

Z1:
88 – 91
Z4:
03 –
1 Series:
04 – 12
1502, 1602, 1802:
62 – 77
2000, 2500, 2800, 3000 CS-CSL:
65 – 76
2002:
68 – 77
2500, 2800, 3000:
68 – 77
3 Series: 390X, E21, E30, E36, E46, E90L, E91, E92, E93
75 – 12
5 Series: E12, E28, E34, E39, E560X, E60, E61
72 – 10
6 Series Convertible:
04 – 11
6 Series Coupe:
04 – 11
6 Series:
68 – 76
6 Series: Incl M6
76 – 90
7 Series:
77 – 86
7 Series:
86 – 94
7 Series:
94 – 01
7 Series: Limo. Security pack
97 – 98
8 Series:
90 – 99
M1:
78 – 81
M3:
86 – 13
M5 3.6i/3.8i/Touring:
88 – 97
M5 5.0i V8 32v:
98 – 04
M5 Touring:
07 – 10
M5:
80 – 89
M5:
04 – 11
M6 Cabrio:
06 – 10
M6:
05 – 11
X1:
09 –
Z3:
95 – 03
Z3M:
98 – 03
Z4M:
06 – 10
Z8. Roadster:
00 – 03[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/2″ offset=”vc_hidden-sm vc_hidden-xs”][vc_icon icon_fontawesome=”fa fa-arrow-circle-right” color=”custom” size=”lg” align=”right” css_animation=”left-to-right” custom_color=”#dd3333″ link=”url:http%3A%2F%2Fwww.alloywheelnutsandbolts.co.uk%2Fproduct-category%2Fwheel-bolts%2F%3Ffilter_hex-size%3D738%26filter_thread-size%3D741%26filter_thread-length%3D746%26filter_seat-type%3D751||”][/vc_column_inner][/vc_row_inner][vc_row_inner][vc_column_inner width=”1/2″][vc_column_text]Spec:

M12x1.5
26mm Length
17mm Hex
Taper Seat[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/2″ offset=”vc_hidden-lg vc_hidden-md”][vc_icon icon_fontawesome=”fa fa-arrow-circle-down” color=”custom” size=”lg” align=”right” css_animation=”top-to-bottom” custom_color=”#dd3333″][/vc_column_inner][/vc_row_inner][/vc_column][vc_column width=”3/4″]

[/vc_column][/vc_row][vc_row][vc_column][vc_separator align=”align_left”][/vc_column][/vc_row][vc_row][vc_column width=”1/4″][vc_empty_space height=”30″][vc_row_inner][vc_column_inner width=”1/2″][vc_column_text]Model
Year

1 Series: F20, F21
11 –
2 Series: F22, F23, F45, F46
14 –
M2:
14 –
3 Saloon: F30, F31, F34
12 –
4 Series: F32, F33, F36
13 –
5 Series GT: F07
09 –
5 Series: F10, F11
10 –
6 Series Convertible: F12
11 –
6 Series Coupe: F13
11 –
6 Series: Gran Coupe F06
11 –
7 Series: F01
08 –
i3:
13 –
M3: F30
14 –
M4:
14 –
M5: F10
12 –
M6: 6C
12 –
X3: F25
10 –
X4:
14 –
X5 M50d:
12-
X5: F15
13 –
X5: E70
07 – 13
X6: E71, F16
08 –
i8:
14 –[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/2″ offset=”vc_hidden-sm vc_hidden-xs”][vc_icon icon_fontawesome=”fa fa-arrow-circle-right” color=”custom” size=”lg” align=”right” css_animation=”left-to-right” custom_color=”#dd3333″][/vc_column_inner][/vc_row_inner][vc_row_inner][vc_column_inner width=”1/2″][vc_column_text]Spec:

M14x1.25
27mm Length
17mm Hex
Taper Seat[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/2″ offset=”vc_hidden-lg vc_hidden-md”][vc_icon icon_fontawesome=”fa fa-arrow-circle-down” color=”custom” size=”lg” align=”right” css_animation=”top-to-bottom” custom_color=”#dd3333″][/vc_column_inner][/vc_row_inner][/vc_column][vc_column width=”3/4″]
